Power supply, 2-12 V AC/DC

Specifications

By simply selecting the proper voltage, this power supply is the solution for those experiments that requires a voltage supply up to 12 V.
The AC/DC power supply can provide a voltage from 1 to 12 V in steps of 1 V, adjustable by means of a rotating knob at the frontal panel.
The equipment is provided with overloading and short circuit protection.
The AC current is supplied through a couple of blue sockets while the DC current is supplied through a pair of colour coded sockets (black/red).
The earth connection point is placed between AC and DC sockets.
Does not include connection cables (QLN005/QLN006)
Power supply 220-240 V AC, 50 Hz
Output voltage AC/DC 1-12 V
Intensity 6 A máx.
Primary protection Fuse 2 A
Secondary protection Thermal switch
